Overview
Detailed PhotosCompany Profile Zhejiang Keyi Electric Group Co.,Ltd., founded in 2004, is located in chengdong industry zone Yueqing, Zhejiang province,China.
The enterprise has passed ISO9001 international quality system certification, the main products:heavy connectors (or rectangular connectors / rectangular connector) and industrial plugs, widely used inconstruction machinery, textile machinery, packaging and printing machinery, tobacco machinery, electriclocomotive and signal connection device. CONWEE has become internationally recognized standardelectrical connecting components.
Extension of the deep electrical limited company through the introduction of advanced technology.professional, high-end equipment and other aspects of the effort, as the extension of the deep providecontinuous power steadily improving series product performance. With excellent quality, CONWELL's heavyduty connectors have been exported to Europe, America and other countries and regions, and customersget a good market feedback.
CONWELL insist on good quality, fast service, we believe passion of technology and built a prosperity electrical world.
Basic Info.
Model NO. | HE-032-F |
Gender | Female |
Housings | Metal |
Contact Finish | Tin |
Fastening Type | Screw |
Termination | Press-Fit |
Mounting Type | Surface Mount |
Limiting Temperature | -40ºC...+125ºC |
Color | Grey |
Flammability | V0 |
Pollution Degree | 3 |
Transport Package | Carton |
Specification | 16A 500V |
Trademark | CONWELL |
Origin | China |
Product Description
Product DescriptionProduct ParametersInsert | Hoods/Housings: Matching 32B Hood Housing |
Number of Contacts | 32 |
-Rated Current | 16A |
-Rated Voltage | 500V |
-Rated Impulse Voltage | 6KV |
-Pollution Degree | 3 |
-Or | |
-Rated Voltage Acc.to Ul CSA | 600V |
Insulation Resistance | ≥1010Ω |
Material | Polycarbonate |
Limiting Temperatures | -40ºC...+125ºC |
Flammability Acc. To UL94 | V0 |
MecHEnical Working Life-mating Cycles | ≥500 |
Crimp Contact | |
Material | Copper Alloy |
Surface | Silver plated/Gold plated |
Contact Resistance | ≤1mΩ |
Terminal | Screw Terminal |
Wire Gauge | 0.14-4mm² |
AWG | 26-14 |
Tightening Torque | 0.5N·m |
The enterprise has passed ISO9001 international quality system certification, the main products:heavy connectors (or rectangular connectors / rectangular connector) and industrial plugs, widely used inconstruction machinery, textile machinery, packaging and printing machinery, tobacco machinery, electriclocomotive and signal connection device. CONWEE has become internationally recognized standardelectrical connecting components.
Extension of the deep electrical limited company through the introduction of advanced technology.professional, high-end equipment and other aspects of the effort, as the extension of the deep providecontinuous power steadily improving series product performance. With excellent quality, CONWELL's heavyduty connectors have been exported to Europe, America and other countries and regions, and customersget a good market feedback.
CONWELL insist on good quality, fast service, we believe passion of technology and built a prosperity electrical world.
