1080P 1 to 4 Video Audio BNC Splitter SD/HD/3G SDI Splitter

Basic Info.

Model NO.	EL-SDI104
Wire Core Material	Red Copper Wire
Certification	RoHS, CE
Brand	Elandphone
Transport Package	Color Box
Specification	Rectangle
Trademark	OEM
Origin	China
Production Capacity	20000PCS/Month

Product Description

Product Description

Key Specifications/Special Features:

1:One Signal distribute to four SDI signal out.
2:Support SD-SDI, HD-SDI and 3G-SDI Video Format.
3:SDI Supports1080P/1080I/720P/576I/ 480I Video Resolution.
4:Support SDI transmission Speed: SD-SDI:270MbPs,HD-SDI:1.485GbPs and 3G-SDI: 2.97GbPs.
5:Supported Max Cable Length(SYV-75-5):SD supports up to 400m,
6:HD supports up to 200m, 3G supports up to 80~100m(Note: The cable length will depend on the cable spec)
7:Support deep color 8bit, 10bit, 12bit
8:Support up to 3G-SDI
9:Audio and Video Output Simultaneously
10:Support Clock Recovery
11:No Any Drive Need, Support Hot-Plug, Plug and Play
12:Wide voltage input, It can support DC 5V~ 12V input
